Waste Oil Furnaces
______________________
EL-140H
Information
______________________
Amount of Space Unit Heats
up to 3500 Square feet
Commonly Used Fuels
Used crankcase oils, ATF, hydraulic fluid, No. 2 fuel oil, and diesel fuel
Fuel Meter Pump
Precision metering over a wide range of fuels
UL Certification
UL listed system
Fuel Flow Rate
1.0 gallons/3.78 liters per hour
BTU Input
142,000 BTU/41.6 kW per hou
Warm Air Temp. Rise
100-120 F/37.8-48.9 C
Air Flow
1000 cfm/28 cu. m/min
Warm Air Outlet Dimensions
12"W x 12"H /31cm W x 31cm H
Ductible dual outlets
Air outlet can be on both sides
Primary Heat Exchanger
18 gauge high temperature and corrosion resistant stainless steel, UL-rated at 1500 F/816 C
System Dimensions
Cabinet -
18"H x 18"W x 92"L / 46cm H x 46cm W x 234cm L
With Tank -
37.5"H x 32"W x 60"L (69"L w/pump)
95cm H x 82cm W x 153cm L (176cm L w/pump)
Hour Meter
Analog (Clocks only actual burn time, not blower)
Exhaust Flue Diameter
8" / 20.32cm diameter
Fuel Tank
Single wall 250 gal./946.35 liter workbench. Double wall workbench available
Electrical Req.
115 VAC 60Hz, 25 amps dedicated circuit
Shipping Weight
System with tank - 730lbs. / 332kg
System without tank - 375lbs. / 171kg
Standard Features
Integrated Air Compressor Barometric Damper, Draft Gauge, Squirrel Cage Blower
Optional Features
Various Size Fuel Tanks, Dual Warm Air Outlet Louvers
______________________
EL-200H
______________________
Information
Amount of Space Unit Heats
up to 5000 Square feet
Commonly Used Fuels
Used crankcase oils, ATF, hydraulic fluid, No. 2 fuel oil, and diesel fuel
Fuel Meter Pump
Precision metering over a wide range of fuels
UL Certification
UL listed system
Fuel Flow Rate
1.4 gallons/ 5.3 liters per hour
BTU Input
200,000 BTU/58.3 kW per hour
Warm Air Temp. Rise
100-120 F/37.8-48.9 C
Air Flow
1500 cfm/42 cu. m/min
Warm Air Outlet Dimensions
15"W x 15"H /38cm W x 38cm H
Ductible dual outlets
Air outlet can be on both sides
Primary Heat Exchanger
18 gauge high temperature and corrosion resistant stainless steel, UL-rated at 2000 F/1093 C
System Dimensions
Cabinet -
18"H x 18"W x 105"L / 46cm H x 46cm W x 267cm L
With Tank -
37.5"H x 32"W x 60"L (69"L w/pump)
95cm H x 82cm W x 153cm L (176cm L w/pump)
Hour Meter
Analog (Clocks only actual burn time, not blower)
Exhaust Flue Diameter
8" / 20.32cm diameter
Fuel Tank
Single wall 250 gal./946.35 liter workbench. Double wall workbench available
Electrical Req.
115 VAC 60Hz, 25 amps dedicated circuit
Shipping Weight
System with tank - 750lbs. / 341kg
System without tank - 395lbs. / 180kg
Standard Features
Integrated Air Compressor Barometric Damper, Draft Gauge, Squirrel Cage Blower
Optional Features
Various Size Fuel Tanks, Dual Warm Air Outlet Louvers
______________________
EL-350H
______________________
Information
Amount of Space Unit Heats
up to 9000 Square feet
Commonly Used Fuels
Used crankcase oils, ATF, hydraulic fluid, No. 2 fuel oil, and diesel fuel
Fuel Meter Pump
Precision metering over a wide range of fuels
UL Certification
UL listed system
Fuel Flow Rate
2.5 gallons/ 9.4 liters per hour
BTU Input
350,000 BTU/102 kW per hour
Warm Air Temp. Rise
100-120 F/37.8-48.9 C
Air Flow
2600 cfm/74 cu. m/min
Warm Air Outlet Dimensions
15"W x 15"H /38cm W x 38cm H
Ductible dual outlets
Air outlet can be on both sides
Primary Heat Exchanger
18 gauge high temperature and corrosion resistant stainless steel, UL-rated at 2000 F/1093 C
System Dimensions
Cabinet -
22"H x 22"W x 117"L / 56cm H x 56cm W x 297cm L
Hour Meter
Analog (Clocks only actual burn time, not blower)
Exhaust Flue Diameter
8" / 20.32cm diameter
Fuel Tank
Single wall 250 gal./946.35 liter workbench. Double wall workbench available
Electrical Req.
115 VAC 60Hz, 25 amps dedicated circuit
Shipping Weight
System with tank - 770lbs. / 349kg
System without tank - 415lbs. / 188kg
Standard Features
Integrated Air Compressor Barometric Damper, Draft Gauge, Squirrel Cage Blower
Optional Features
Various Size Fuel Tanks, Dual Warm Air Outlet Louvers
